Centrifugal dewatering machine

Item Code: Features:
  • Description

-    Motor controlled by inverter

MATERIAL OF PARTS
TUBE 304 STAINLESS STEEL
ROTATING CAGE 304 STAINLESS STEEL
OUTTER SHELL 202 STAINLESS STEEL
ELECTRIC CABINET SHELL 202 STAINLESS STEEL

HANK DEWATERER

S/N 1 2 3 4
Diameter(mm) 300 450 600 800
Rotate speed(r/min) 1500 1300 1100 960
Volume(kg) 10 20 50 80
Power(kw) 0.75 1.5 3 5.5
Dimension(mm)  450*550*450  600*700*550  800*900*650 1450*1500*800



S/N

5 6 7
Diameter(mm) 1000 1200 1200
Rotate speed(r/min) 900 720 800
Volume(kg) 100 150 180
Power(kw) 7.5 7.5 11
Dimension(mm) 1600*1700*900 1700*1800*950 1750*1850*950



TUBE-SHAPED DEWATERER

S/N 1 2 3
Rotating cage inner diameter(mm) 300 600 800
Cage number(pcs) 1 6~12 11~22
Power(kw) 0.75 4 5.5
Rotate speed(rdm) 1500 1100 960
Dimension(mm)  450*550*450 800*900*700  1450*1500*950



S/N 4 5
Rotating cage inner diameter(mm) 1000 1200
Cage number(pcs) 24~36 51~72
Power(kw) 7.5 7.5
Rotate speed(rdm) 900 800
Dimension(mm) 1600*1700*1000 1700*1800*1200

Use:
    The centrifugal extractor machines with different configurations are used for dewatering the bobbin, hank and cloth.

Main specifications:

  • Material of tube: 304 stainless steel
  • Material of rotating cage: 304 stainless steel
  • Material of outter shell: 202 stainless steel
  • Material of electric cabinet shell:202 stainless steel
  • Motor controlled by inverter


Technical Features:

  • Lid open /close by pneumatic
  • High-quality stainless steel for tube and cage for long lifespan.
  • Large capacity, high dehydration rate and low power consumption
  • Reliable automatic system with advanced frequency control, automatic time count, automatic brake, rotating speed can be set in advance.
  • Automatic frequency control to avoid mechanical brakes for purpose of reducing the rate of mechanical maintenance.
  • Super quiet balancing for first class working environment.
